| GENERAL DESCRIPTION |
Product Features
| TECHNICAL SPECIFICATIONS | ||
| Frequency range | 3.2 - 26.1 MHz | |
| Polarization | Horizontal | |
| Gain | ≥ 6.5 dB | |
| Directivity | Omnidirectional | |
| VSWR | ≤ 2.5 | |
| Max. power | 100 kW | |
| Feeder impedance | 300 Ω | |
| Antenna height | 27 m | |
| Operating | -40 - +55°C | |
| Max. wind velocity | 36 m/s | |
| Dimensions | 77 x 46 x 27 m | |
| Antenna weight | ∼600 kg | |
| Specifications may change without notice | ||
