| GENERAL DESCRIPTION |
Product Features
| TECHNICAL SPECIFICATIONS | ||
| Frequency range | 3.2 - 26.1 MHz, 5.9 - 26.1 MHz | |
| Polarization | Horizontal | |
| Gain | ≥ 10 dB | |
| VSWR | ≤ 2.5 | |
| Max. power | 10 kW | |
| Feeder impedance | 50 Ω | |
| Front to back ratio | ≥ 9 dB | |
| Horizontal half-power beamwidth | 60° - 80° | |
| Step | 1° | |
| Duration of one circle | ≤ 5 mins | |
| Seismic fortification intensity | 9° | |
| Max. wind velocity | 36 m/s | |
| Specifications may change without notice | ||
